1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP102 |
Adjustable | Yes |
Wattage | 10W/15W/24W/30W/40W/50W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/38/60 |
Lumen | 1050lm/1570lm/2520lm/3100lm/4200lm/5200lm |
Finish | Matt white or black trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ90*H60mm for 10W Φ102*H80mm for 15W Φ125*H110mm for 24W Φ140*H115mm for 30W Φ160*H135mm for 40W Φ190*H175mm for 50W |
Cutout size | Φ75mm for 10W Φ90mm for 15W Φ110mm for 24W Φ128mm for 30W Φ148mm for 40W Φ180mm for 50W |
LED source | COB, CREE/BRIDGELUX |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
