1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP107 |
Adjustable | Yes |
Wattage | 7W/10W/12W/25W/35W/2*7W/2*12W/2*25W/2*35W/3*7W/3*12W/3*25W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/38 |
Lumen | 735lm/1050lm/1260lm/2620lm/3675lm/1470lm/2520lm/5240lm/7350lm/2205lm/3780lm/7860lm |
Finish | Matt white or black trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ72*H110mm for 7W Φ85*H102mm for 10W Φ103*H120mm for 12W Φ130*H135mm for 25W Φ160*H155mm for 35W L71*W72*H110mm for 7W L100*W100*H120mm for 12W L130*W130*H135mm for 25W L71*W131*H110mm for 2*7W L100*W185*H120mm for 2*12W L130*W240*h135mm for 2*25W L160*W295*H155mm for 2*35W L72*W192*H110mm for 3*7W L100*W270*H120mm for 3*12W L130*W345*H135mm for 3*25W |
Cutout size | Φ65mm for 7W Φ75mm for 10W Φ90mm for 12W Φ120mm for 25W Φ140mm for 35W L65*W121mm for 2*7W L90*W175mm for 2*12W L120*W230mm for 2*25W L140*W280mm for 2*35W L65*W182mm for 3*7W L90*W260mm for 3*12W L120*W335mm for 3*25W |
LED source | COB, CREE/BRIDGELUX |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
