1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP129 |
Wattage | 10W/15W/20W/30W/40W/50W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/36/50 degree |
Lumen | 1260lm/1890lm/2520lm/3150lm/4200lm/5050lm |
Finish | Matt white trim |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ85*H55mm for 10W Φ110*H65mm for 15W Φ140*H75mm for 20W Φ160*H85mm for 30W Φ185*H95mm for 40W Φ215*H108mm for 50W |
Cutout size | Φ 75mm for 10W Φ 95mm for 15W Φ 120mm for 20W Φ 140mm for 30W Φ 160mm for 40W Φ 200mm for 50W |
LED source | COB, Cree/Bridgelux |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
