1.USe high performance LED,CRI>80/90
2.Aluminum heat sink and unique Die casting heat sink design ensures good heat dissipation.
3.LED source Osram or San'an can be optional.
4.Driver brand can be optional
5.Application: Direct replacement for luminaires with compact fluorecent lamps,general illumination,public areas,stairways,corridors,foyers,shops
Item No. | IBSP136 |
Adjustable | Yes |
Wattage | 5W/7W/10W/15W/18W/20W/30W |
CRI | 80/90 |
CCT | 2700K/3000K/3500K/4000K/5000K/5700K/6500K |
Beam angle | 15/24/38 |
Lumen | 425lm/595lm/850lm/1530lm/1700lm/2550lm |
Finish | Matt white |
IP rating | IP20 |
Material | Die-casting alu.trim and heatsink,PMMA lens |
Driver | Constant current remote LED driver included |
Product Size | Φ63*H63mm for 5W Φ63*H78mm for 10W Φ85*H71mm for 7W Φ85*H76mm for 10W Φ85*H93mm for 18W Φ105*H99mm for 20W Φ105*H115mm for 30W |
Cutout size | Φ55mm for 5W Φ55mm for 10W Φ75mm for 7W Φ75mm for 10W Φ75mm for 18W Φ95mm for 20W Φ95mm for 30W |
LED source | COB, CREE/BRIDGELUX |
Input Voltage | 220-240vac/100-240vac |
Diming | Non Dim/Triac/0-10V/Dali Dim |
